AC/DC Power Supplies :: PCB Mount

Series Datasheet Power Input Range Outputs Dimensions Features
AZC AZC Download » 2 90-305 VAC or 120-430 VDC Single 1.12 x 1.02 x 0.67 In
28.5 x 25.8 x 17.0 mm
PCB Mount
AYC AYC Download » 2 90-305 VAC or 120-430 VDC Single 1.33 x 0.87 x 0.67 In
33.7 x 22.2 x 17.0 mm
PCB Mount
AIC AIC Download » 3 90-264 VAC or 120-370 VDC Single 1.41x 0.75 x 0.86 In
35.7 x 19.0 x 22.0 mm
PCB Mount
AOC AOC Download » 4 90-264 VAC or 120-370 VDC Single, Dual 1.44 x 1.07 x 0.67 In
36.7 x 27.16 x 17.1 mm
PCB Mount
AOCH AOCH Download » 4 90-305 VAC or 120-430 VDC Single, Dual 1.44 x 1.07 x 0.67 In
36.66 x 27.16 x 17.1 mm
PCB Mount
AHC AHC Download » 5 90-264 VAC or 120-370 VDC Single 2.0 x 1.0 x 0.597 In
50.8 x 25.4 x 15.16 mm
PCB Mount
APC APC Download » 5 90-264 VAC or 120-370 VDC Single, Dual 2.15 x 1.77 x 0.82 In
55.0 x 45.0 x 21.0 mm
PCB Mount
AHC-E1 AHC-E1 Download » 5 90-264 VAC or 120-370 VDC Single 2.0 x 1.0 x 0.597 In
50.8 x 25.4 x 15.16 mm
Switching power module for PCB Mountable, Fully Encapsulated Plastic Case, Universal Input Range 90-264Vac, Regulated output and low ripple and low noise, Isolation Class II, Small Size , Screw Teminal For optional, 3- years product warranty
AUC AUC Download » 7 90-264 VAC or 120-370 VDC Single 1.08 x 1.08 x 0.736 In
27.4 x 27.4 x 18.7 mm
PCB Mount
ALC ALC Download » 8 90-305 VAC or 120-430 VDC Single, Dual 1.48 x 1.11 x 1.08 In
37.66 x 28.16 x 27.5 mm
PCB Mount
AHC08 AHC08 Download » 8 90-305 VAC or 120-430 VDC Single, Dual 2.055 x 1.055 x 0.75 In
52.2 x 26.8 x 19.0 mm
PCB Mount
AFC-E1 AFC-E1 Download » 10 90 - 264 VAC or 120 - 370 VDC Single 2.07 x 1.08 x 0.93 In
52.5 x 27.5 x 23.5mm
AC / DC Power Module
ATC ATC Download » 10 90-264 VAC or 120-370 VDC Single, Dual 2.52 x 1.77 x 0.85 In
64.0 x 45.0 x 21.5 mm
PCB Mount
AFC AFC Download » 10 90 - 264 VAC or 120 - 370 VDC Single 2.07 x 1.08 x 0.93 In
52.5 x 27.5 x 23.5mm
AC / DC Power Module
ANCA-E1 ANCA-E1 Download » 15 90-264 VAC or 120-370 VDC Single, Dual, Triple 2.91 x 2.13 x 0.86 In
74.0 x 54.0 x 22.0 mm
PCB Mount
AVC AVC Download » 15 90-264 VAC or 120-370 VDC Single 1.62 x 1.07 x 0.75 In
41.2 x 27.2 x 19.1 mm
PCB Mount
MTC-E1 MTC-E1 Download » 15 90-264 VAC or 100-375 VDC Single, Dual, Triple 2.52 x 1.79 x 0.92 In
64.0 x 45.6 x 23.5 mm
PCB Mount
ANCA ANCA Download » 15 90-264 VAC or 120-370 VDC Single, Dual, Triple 2.91 x 2.13 x 0.86 In
74.0 x 54.0 x 22.0 mm
PCB Mount
MTC MTC Download » 15 90-264 VAC or 100-375 VDC Single, Dual, Triple 2.52 x 1.79 x 0.92 In
64.0 x 45.6 x 23.5 mm
PCB Mount
AKC AKC Download » 20 90-264 VAC or 100-375 VDC Single, Dual, Triple 2.76 x 1.89 x 0.87 In
70.0 x 48.0 x 22.0 mm
PCB Mount
AFC20 AFC20 Download » 20 90-264 VAC or 120-370 VDC Single 2.07 x 1.08 x 0.93 In
52.6 x 27.4 x 23.5 mm
PCB Mount
ASC ASC Download » 30 90-264 VAC or 120-370 VDC Single, Dual, Triple 3.5 x 2.5 x 0.98 In
89.5 x 64.1 x 25.0 mm
PCB Mount
ATC30 ATC30 Download » 30 90-305VAC or 120-430VDC Single 2.52 x 1.77 x 0.92 In
64.0 x 45.0 x 23.5 mm
PCB Mount
MSC-E1 MSC-E1 Download » 40 90-264 VAC or 100-375 VDC Single, Dual, Triple 3.5 x 2.5 x 1.06 In
89.0 x 63.5 x 27.0 mm
PCB Mount
AJC AJC Download » 40 90-264 VAC or 100-375 VDC Single, Dual, Triple 3.5 x 2.5 x 0.98 In
89.5 x 64.1 x 25.0 mm
PCB Mount
MSC MSC Download » 40 90-264 VAC or 100-375 VDC Single, Dual, Triple 3.5 x 2.5 x 1.06 In
89.0 x 63.5 x 27.0 mm
PCB Mount
ANC50 ANC50 Download » 50 90-264 VAC or 120-370 VDC Single 2.91 x 2.13 x 0.86 In
74.0 x 54.0 x 22.0 mm
PCB Mount
AEC60 AEC60 Download » 60 90-264 VAC or 130-370 VDC Single 4.3 x 2.3 x 1.18 In
109.0 x 58.5 x 30 mm
PCB Mount
AQC100 AQC100 Download » 100 90-264 VAC or 120-370 VDC Single 4.3 x 2.3 x 1.18 In
109.0 x 58.5 x 30 mm
PCB Mount
AQC125 AQC125 Download » 125 90 - 264 VAC or 120 - 370 VDC Single 5.83 x 2.8 x 1.5 In
148.0 x 71.0 x 38.0 mm
PCB Mount

AC/DC Power Supplies :: Open Frame | Enclosed | U-Chassis

Series Datasheet Power Input Range Outputs Dimensions Features
AES60O AES60O Download » 60 90-264 VAC or 120-370 VDC Single 4.1 x 2.05 x 1.0 In
103.9 x 52.1 x 25.4 mm
Open Frame
AES60U AES60U Download » 60 90-264 VAC or 120-370 VDC Single 4.13 x 2.28 x 1.5 In
105.0 x 58.0 x 38.1 mm
U Bracket
AES60E AES60E Download » 60 90-264 VAC or 120-370 VDC Single 4.13 x 2.28 x 1.5 In
105.0 x 58.0 x 38.1 mm
Enclosed Frame
SZA60O Series SZA60O Series Download » 60 90-264 VAC or 120-370 VDC Single 3.0 x 2.0 x 1.24 In
76.3 x 50.6 x 31.5mm
Open Frame Switching Power Supply, Universal Input: 90 - 264 VAC, Single Ouput , <0.3W No Load Input Power, 5 VDC to 48 VDC Output, 3000 VAC Input to Output Isolation, Ultra Compact Size, 3- Years Product Warranty
SZA60U Series SZA60U Series Download » 60 90-264 VAC or 120-370 VDC Single 3.15 x 2.26 x 1.5 In
80.0 x 57.5 x 38.0 mm
Open Frame Switching Power Supply, Universal Input: 90 - 264 VAC, Single Ouput , <0.3W No Load Input Power, 5 VDC to 48 VDC Output, 3000 VAC Input to Output Isolation, Ultra Compact Size, 3- Years Product Warranty
AQF100C AQF100C Download » 100 90-264 VAC or 120-370 VDC Single 4.1 x 2.05 x 0.98 In
103.9 x 52.1 x 25.0 mm
AC/DC Power Supply, Open Frame
AQF100O AQF100O Download » 100 90-264 VAC or 120-370 VDC Single 4.1 x 2.05 x 0.98 In
103.9 x 52.1 x 25.0 mm
AC/DC Power Supply, Open Frame
SZA100 Series SZA100 Series Download » 100 85- 265 Single Output 4.05 x 2.04 x 1.36 Inches ( 102.75 x 51.7 x 34.5 mm ) Tolerance ±0.5mm Open Frame Switching Power Supply, Universal Input : 85-265 VAC, Single Output, <0.3w No Load Input Power (48Vout <0.5W), 12VDC to 48 VDC Output, 3000 VAC input to Output Isolation, Ultra Compact Size, 3- Years Prduct Warranty
AQF120O AQF120O Download » 120 90-264 VAC or 100-370 VDC Single 5.0 x 3.0 x 1.16 In
127.0 x 76.2 x 29.5 mm
Open Frame
AQF120U AQF120U Download » 120 90-264 VAC or 100-370 VDC Single 5.0 x 3.24 x 1.5 In
127.0 x 82.2 x 38.1 mm
U Bracket
AQF120E AQF120E Download » 120 90-264 VAC or 100-370 VDC Single 5.0 x 3.24 x 1.5 In
127.0 x 82.2 x 38.1 mm
Enclosed Frame
AQF160 AQF160 Download » 160 90-264 VAC or 120-370 VDC Single 4.1 x 2.05 x 1.42 In
103.9 x 52.1 x 29.0 mm
Open Frame
AQF120E-180W AQF120E-180W Download » 180 90-264 VAC or 100-370 VDC Single 5.0 x 3.24 x 1.5 In
127.0 x 82.2 x 38.1 mm
Enclosed Frame
AQF120U-180W AQF120U-180W Download » 180 90-264 90-264 VAC or 120-370 VDC (80-274 VAC or 110-390 VDC with Derating)VAC or 100-370 VDC Single 5.0 x 3.24 x 1.5 In
127.0 x 82.2 x 38.1 mm
U Bracket
AQF240U AQF240U Download » 240 90-264 VAC or 120-370 VDC Single 5S:6.0 x 4.18 x 1.46 In, 150.0 x 106.0 x 35.0 mm
Others:6.0 x 4.18 x 1.38 In, 150.0 x 106.0 x 35.0 mm
AC-DC U Bracket
AQF240E AQF240E Download » 240 90-264 VAC or 120-370 VDC Single 6.0 x 4.18 x 1.38 In
150.0 x 106.0 x 35.0 mm
AC-DC Enclosed Frame
AQF360U AQF360U Download » 360 90-264 VAC or 120-370 VDC Single 6.8 x 3.2 x 1.5 In
172.7 x 81.3 x 38.0 mm
AC-DC U Bracket
AQF360E AQF360E Download » 360 90-264 VAC or 120-370 VDC Single 6.8 x 3.2 x 2.1 In
172.7 x 81.3 x 53.3 mm
AC-DC Enclosed Frame
AQF360F AQF360F Download » 360 90-264 VAC or 120-370 VDC Single 7.8 x 3.2 x 1.57 In
197.7 x 81.3 x 40.0 mm
AC-DC Enclosed Frame
AQFC480U AQFC480U Download » 480 90-264 VAC or 120-370 VDC Single -12V / 24V / 36V / 48V 7.0 x 4.2 x 1.78 Inches (177.8 x 106.5 x 45.0 mm ) Tolerance ±0.5 mm AC/DC Power Supply U Bracket
AQFC480E AQFC480E Download » 480 90-264 VAC or 120-370 VDC Single 7.0 x 4.2 x 2.37 In
177.8 x 106.5 x 60.3 mm
AC/DC Power Supply Enclosed
AQFV480E AQFV480E Download » 480 90-264 VAC or 120-370 VDC Single 7.0 x 4.2 x 2.37 In
177.8 x 106.5 x 60.3 mm
AC/DC Power Supply Enclosed
AQFC480F AQFC480F Download » 480 90-264 VAC or 120-370 VDC Single 7.98 x 4.2 x 1.78 In
202.8 x 106.5 x 45.0 mm
AC/DC Power Supply Enclosed
AQFV480F AQFV480F Download » 480 90-264 VAC or 120-370 VDC Single 7.98 x 4.2 x 1.78 In
202.8 x 106.5 x 45.0 mm
AC/DC Power Supply Enclosed
AQF600 AQF600 Download » 600 90-264 VAC or 120-370 VDC Single 9.0 x 4.13 x 1.72 Inches (228.5 x 105 x 44 mm) AC/DC Power Supply Enclosed

DC/DC :: Open Frame | Enclosed | U-Chassis

Series Datasheet Power Input Range Outputs Dimensions Features
ST60 ST60 Download » 60 48V (18-72V) Single 2.08 x 1.08 x 0.53 Inches Enclosed

DC/DC :: PCB Mount

Series Datasheet Power Input Range Outputs Dimensions Features
SB1R5 SB1R5 Download » 2 5VDC
12VDC
24VDC
48VDC
Single, Dual 1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm
DC-DC PCB Mount
SB03 SB03 Download » 3 24VDCln
48VDC
Single, Dual 1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm
DC-DC PCB Mount
SB05 SB05 Download » 5 24VDC
48VDC
Single, Dual 1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm
DC-DC PCB Mount
SH05 SH05 Download » 5 24VDC
48VDC
Single, Dual 1.25 x 0.8 x 0.44 In
31.8 x 20.3 x 11.2 mm
DC-DC PCB Mount
ZA05 ZA05 Download » 5 24V--9-36VDC
48V--18-75VDC
Single, Dual 1.25 x 0.8 x 0.4 In31.8 x 20.3 x 10.2 mm DC-DC PCB Mount
SB08 SB08 Download » 8 2:1 Range: 12VDC, 24VDC, 48VDC
4:1 Range: 24VDC, 48VDC
Single, Dual 1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm
DC-DC PCB Mount
SH08 SH08 Download » 8 24VDC
48VDC
Single, Dual 1.25 x 0.8 x 0.44 In
31.8 x 20.3 x 11.2 mm
DC-DC PCB Mount
SH10 SH10 Download » 10 12V--9-18VDC
24V--18-36VDC
48V--36-75VDC
Single, Dual 1.25 x 0.8 x 0.44 In
31.8 x 20.3 x 11.2 mm
DC-DC PCB Mount
ST10 ST10 Download » 10 2:1 Range: 12V--9-18, 24V--18-36, 28V--36-75VDC
4:1 Range: 24V--10-40, 48V--36-75VDC
Single, Dual 1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm
DC-DC PCB Mount
ZB15 ZB15 Download » 15 12V--9-18VDC
24V--18-36VDC
48V--36-75VDC
Single, Dual 1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm
DC-DC PCB Mount
SW15 SW15 Download » 15 128V--9-1VDC
24V--18-36VDC
48V--36-75
Single 1.0 x 1.0 x 0.433 In
25.4 x 25.4 x 11.0 mm
DC-DC PCB Mount
ST15 ST15 Download » 15 2:1 Range: 12V--9-18, 24V--18-36, 48V--36-75VDC
4:1 Range: 24F--10-40, 48V--18-75VDC
Single, Dual 1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm
DC-DC PCB Mount
SW20 SW20 Download » 20 12V--9-18VDC
24V--18-36VDC
48V--36-75VDC
Single 1.0 x 1.0 x 0.433 In
25.4 x 25.4 x 11.0 mm
DC-DC PCB Mount
ST20 ST20 Download » 20 2:1 Range: 24V--18-36VDC
48V--36-75VDC
Single 1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm
DC-DC PCB Mount
SU20 SU20 Download » 20 2:1 Range: 12VDC, 24VDC, 48VDC
4:1 Range: 24VDC, 48VDC
Single, Dual,Triple 2.0 x 2.0 x 0.45 In
50.8 x 50.8 x 11.4 mm
DC-DC PCB Mount
ST30 ST30 Download » 30 24VDC
48VDC
Single, Dual 2.0 x 1.0 x 0.433 In
50.8 x 25.4 x 11.0 mm
DC-DC PCB Mount
SF30 SF30 Download » 30 24VDC
48VDC
Single, Dual 2.0 x 1.6 x 0.47 In
50.8 x 40.6 x 11.9 mm
DC-DC PCB Mount
SK30 SK30 Download » 30 48V--36-75VDC Single 2.0 x 1.6 x 0.47 In
50.8 x 40.6 x 11.9 mm
DC-DC PCB Mount
SK40 SK40 Download » 40 48V--36-75VDC Single 2.0 x 1.60 x 0.47 In
50.80 x 40.6 x 11.90 mm
DC-DC PCB Mount
SU40 SU40 Download » 40 2:1 Range: 12V--9-18, 24V--18-36, 48V--36-75VDC Single, Dual,Triple 2.0 x 2.0 x 0.45 In
50.8 x 50.8 x 11.4 mm
DC-DC PCB Mount

AC/DC Power Supplies :: LED Driver

Series Datasheet Power Input Range Outputs Dimensions Features
APF100 APF100 Download » 0 90 - 305 VAC or 120 - 430 VDC Single 5.67 x 2.76 x 1.48 In
144.0 x 70.0 x 37.5 mm
Fully Isolated Plastic Case, Compact Size, Three in one dimming function, Free Air Convection, 100 watts
PLF16 PLF16 Download » 16 90 - 264 VAC Single 3.47 x 1.69 x 1.1 In
88.0 x 43.0 x 28.0 mm
Fully Isolated Plastic Case, Constant Current, High Reliability and Double Layered PCB
PLF25 PLF25 Download » 25 90 - 264 VAC Single 3.47 x 1.69 x 1.1 In
88.0 x 43.0 x 28.0 mm
Fully Isolated Plastic Case, Constant Current, High Reliability and Double Layered PCB
ZQF30-R ZQF30-R Download » 30 90 - 264 VAC Single 4.0 x 2.0 x 1.12 In
101.6 x 50.8 x 28.5 mm
Open Frame, Constant Current and Voltage, High Reliability and Double Layered PCB, Ultra Compact Size
PLF30 PLF30 Download » 30 90 - 264 VAC Single 4.92 x 2.36 x 1.38 In
125.0 x 60.0 x 35.0 mm
Fully Isolated Plastic Case, Constant Current, High Reliability and Double Layered PCB
ZQF30 ZQF30 Download » 30 90 - 264 VAC Single 4.0 x 2.0 x 1.12 In
101.6 x 50.8 x 28.5 mm
Open Frame, Constant Current and Voltage, High Reliability and Double Layered PCB, Ultra Compact Size
ZQF60 ZQF60 Download » 60 90 - 264 VAC Single 4.0 x 2.0 x 1.12 In
101.6 x 50.8 x 28.5 mm
Open Frame, Constant Current and Voltage, High Reliability and Double Layered PCB, Ultra Compact Size
ZQF60-R ZQF60-R Download » 60 90-264 VAC Single 4.0 x 2.0 x 1.12 In
101.6 x 50.8 x 28.5 mm
Open Frame, Constant Current and Voltage, High Reliability and Double Layered PCB, Ultra Compact Size
ALF60 ALF60 Download » 60 90-305 VAC or 127-430 VDC Single 4.72 x 2.36 x 1.38 In
120.0 x 60.0 x 35.0 mm
Three in One Dimming Function, Bulit-in Active PFC Function, LED Power Application
AQF60C AQF60C Download » 60 90-305 VAC or 127-430 VDC Single 4.17 x 2.04 x 1.06 In
106.0 x 52.0 x 27.0 mm
Open Frame
PLF60 PLF60 Download » 60 90 - 264 VAC Single 4.92 x 2.36 x 1.38 In
125.0 x 60.0 x 35.0 mm
Fully Isolated Plastic Case, Constant Current, High Reliability and Double Layered PCB
PSF60 PSF60 Download » 60 90 - 295 VAC Single 5.67 x 2.76 x 1.48 In
144.0 x 70.0 x 37.5 mm
Fully Isolated Plastic Case, Constant Current, High Reliability and Double Layered PCB
QLF60 QLF60 Download » 60 90 - 295 VAC Single 4.72 x 2.36 x 1.38 In
120.0 x 60.0 x 35.0 mm
Indoor and Outdoor LED Installations, Constant Current and Voltage, High Reliability and Double Layered PCB
ZLF60 ZLF60 Download » 60 90 - 295 VAC Single 4.12 x 2.07 x 1.2 In
104.7 x 52.6 x 27.0 mm
Open Frame, Constant Current and Voltage, High Reliability and Double Layered PCB, Ultra Compact Size
PSF75 PSF75 Download » 75 90 - 295 VAC Single 5.67 x 2.76 x 1.48 In
144.0 x 70.0 x 37.5 mm
Fully Isolated Plastic Case, Constant Current, High Reliability and Double Layered PCB
QLF75 QLF75 Download » 75 90 - 295 VAC Single 4.72 x 2.36 x 1.38 In
120.0 x 60.0 x 35.0 mm
Indoor and Outdoor LED Installations, Constant Current and Voltage, High Reliability and Double Layered PCB
ZLF75 ZLF75 Download » 75 90 - 295 VAC Single 4.12 x 2.07 x 1.2 In
104.7 x 52.6 x 27.0 mm
Open Frame, Constant Current and Voltage, High Reliability and Double Layered PCB, Ultra Compact Size
AQF80C AQF80C Download » 80 90-305 VAC or 127-430 VDC Single 4.17 x 2.04 x 1.06 In
106.0 x 52.0 x 27.0 mm
Open Frame
ALF80 ALF80 Download » 80 90-305 VAC or 127-430 VDC Single 4.72 x 2.36 x 1.38 In
120.0 x 60.0 x 35.0 mm
Three in One Dimming Function, Bulit-in Active PFC Function, LED Power Application
ALF100 ALF100 Download » 100 90-305 VAC or 120-430 VDC Single 6.44 x 2.79 x 1.5 In
163.7 x 71.0 x 38.0 mm
Three in One Dimming Function, Bulit-in Active PFC Function, LED Power Application, Available as IP65 or IP67
PSF100 PSF100 Download » 100 90 - 295 VAC Single 5.67 x 2.76 x 1.48 In
144.0 x 70.0 x 37.5 mm
Fully Isolated Plastic Case, Constant Current, High Reliability and Double Layered PCB
QLF100 QLF100 Download » 100 90 - 295 VAC Single 4.72 x 2.36 x 1.38 In
120.0 x 60.0 x 35.0 mm
Indoor and Outdoor LED Installations, Suitable for LED Lighting and moving sign applications, Ultra Compact Size
ZLF100 ZLF100 Download » 100 90 - 295 VAC Single 4.12 x 2.07 x 1.2 In
104.7 x 52.6 x 27.0 mm
Open Frame, Constant Current and Voltage, High Reliability and Double Layered PCB, Ultra Compact Size
ALF150 Series ALF150 Series Download » 150 90-305 VAC or 120-430 VDC Single 6.44 x 2.79 x 1.5 In
163.7 x 71.0 x 38.0 mm
Built-in Active PFC Function, Constant Current and Voltage, Adjustable Current and Voltage, LED Power Application, Available as IP65 or IP67,
APF150 APF150 Download » 150 90-305 VAC or 120-430 VDC Single 5.67 x 2.76 x 1.48 In
144.0 x 70.0 x 37.5 mm
Three in one dimming function, Bulit-in Active PFC Function, Free Air Convection, LED Power Application, 150 Watts
ALF240 Series ALF240 Series Download » 240 90-264 VAC OR 129-370 VDC Single 8.35 x 2.76 x 1.5 In
212.2 x 70.0 x 38.0 mm
Built in Active PFC Function, Three In One Dimming Function, Constant Current and Voltage, Volatage and Current Can Be Adjusted, Available in IP65 or IP67
