DC/DC :: PCB Mount

Victor Power

Series... Datasheet Power Input Range Outputs Dimensions Features
VSF01 Series VSF01 Series Download » 1 Isolated and Unregulated Input Single, Dual 22.00x9.5x12.00mm Ultraminiature SIP
VSB01(H) Series VSB01(H) Series Download » 1 Fixed Input Single 11.6x6.00x10.16mm Miniature SIP
VSA01(H6) Series VSA01(H6) Series Download » 1 Fixed Input Isolated and Unregulated Single, Dual Ultraminiature SIP
VSA01(H) VSA01(H) 1 Fixed Input Isolated and Unregulated Single, Dual 19.5x6x9.35mm (0.768x0.0.236x0.0388 inch) Ultraminuture SIP
VMD01(H) Series VMD01(H) Series Download » 1 Fixed Input Single 12.7*11.2*7.25mm SMD
VMF02(H6) Series VMF02(H6) Series Download » 2 Fixed Input Single 23.86*18.10*8.00mm Ultraminiature SMD
VSF03 (H) Series VSF03 (H) Series Download » 3 Isolated and Regulated Input Single, Dual 0.87 x 0.37 x 0.47 Inch ( 22.0 x 9.5 x 12.0mm ) Ultraminiature SIP
VPA03 (H) Series VPA03 (H) Series Download » 3 2:1 Input Range Single, Dual 31.75x20.3x10.2mm (1.24x0.8x0.4 inch) 24 DIP
VDB05 Series VDB05 Series Download » 5 2:1 Input Nominal 12VDC: 9~18VDC
24VDC: 18~36VDC
48VDC: 36~72VDC
4:1 Input Nominal 24VDC: 9 ~36VDC
48VDC: 18~72VDC		 Single, Dual 31.75x23.32x11.2 mm (1.25x0.8x0.44 inch) Efficiency up to 82%
VDB05-110 Series VDB05-110 Series 5 110VDC Input Nominal 110VDC: 65~140VDC Single, Dual 1x1x0.44 Inch (25.4x25.4x11.2mm) 5 DIP
V78A V78A Download » 7 4.75VDC ~ 32VDC Single SIP
VXB10(W) Series VXB10(W) Series Download » 10 2:1 Input Nominal 12VDC: 9~18 24VDC: 18~36 28VDC: 18~36 48VDC: 36~72
4:1 Input Nominal 24VDC: 15~55 28VDC: 15~55 48VDC: 18~72		 Single 50.8 X 25.4 X 12.7 mm (2 X 1 X 0.5 Inch) DIP
VDA10 Series VDA10 Series Download » 10 2:1 Input Nominal 12VDC: 9~18VDC 24VDC: 18~36VDC 48VDC: 36~72VDC
4:1 Input Nominal 24VDC: 9 ~36VDC 48VDC: 18~72VDC		 Single, Dual 50.8 X 25.4 X 11.2 mm (2.00 X 1.00 X 0.44 Inch) DIP
VDF10W Series VDF10W Series Download » 10 4:1 INPUT 24VDC: 9 ~ 36 VDC 48
VDC: 18~72VDC		 Single, Dual 25.4 x 25.4 x 10.16 mm (1.0 x 1.0 x 0.4 inch) Metal Shielding Package
VXB15(W) Series VXB15(W) Series Download » 15 2:1 Input Nominal 12VDC: 9~18
24VDC: 18~36
28VDC: 18~36
4:1 Input Nominal 24VDC: 15~55
28VDC: 15~55		 Single 50.8 X 25.4 X 12.7 mm (2 X 1 X 0.5 Inch) DIP
VDA15 Series VDA15 Series Download » 15 2:1 Input Nominal 12VDC: 9~18VDC
24VDC: 18~36VDC
48VDC: 36~72VDC		 Single, Dual 50.8 X 25.4 X 11.2 mm (2.00 X 1.00 X 0.44 Inch) DIP
VDC15 Series VDC15 Series Download » 15 2:1 INPUT 12VDC: 9 ~ 18 VDC
24VDC: 18 ~ 36 VDC
48VDC: 36 ~ 72 VDC		 Single, Dual 50.8 X 25.4 X 12.7 mm (2.00 X 1.00 X 0.5 Inch) Metal Case Shielding
V78B V78B Download » 15 4.75VDC~32VDC Single SIP
VDA20(W) Series VDA20(W) Series Download » 20 4:1 Input Nominal 24VDC: 9~36
48VDC: 18~72VDC		 Single 50.8 X 25.4 X 11.2 mm (2.00 X 1.00 X 0.44 Inch) DIP
VDC30 Series VDC30 Series Download » 30 2:1 INPUT 12VDC: 9~18VDC
24VDC: 18~36VDC
48VDC: 36~72VDC		 Single 50.8 X 25.4 X 10.16 mm (2.00 X 1.00 X 0.4 Inch) Enclosed
VHA50(W) Series VHA50(W) Series Download » 50 2:1 & 4:1 Input Voltage Single 57.9 X 61 X 13.5 mm (2.28 X 2.4 X 0.53 Inch) DIP
VQA50 Series VQA50 Series Download » 50 2:1 Input Range 18~36VDC
48~72VDC		 Single 57.9 X 36.8 X 13.5 mm (2.28 X 1.45X 0.53 Inch) DIP
VQA75 Series VQA75 Series Download » 75 2:1 Input Range 18~36VDC
48~72VDC		 Single 57.9 X 36.8 X 13.5 mm (2.28 X 1.45X 0.53 Inch) DIP
VHA75(W) Series VHA75(W) Series Download » 75 2:1 and 4:1 Single 57.9 X 61 X 13.5 mm (2.28 X 2.4 X 0.53 Inch) DIP
VHA100 Series VHA100 Series Download » 100 18~36VDC & 36~75VDC Single 57.9 X 61 X 13.5 mm (2.28 X 2.4 X 0.53 Inch) DIP
VP-28T5-12-5 Series VP-28T5-12-5 Series Download » 107 2:1 INPUT Triple 3”x5”x2” Open Frame
VDA150 Series VDA150 Series Download » 150 2:1 Input Nominal 96VDC: 65~150VDC
110VDC: 82~180VDC
280VDC: 200~400VDC		 Single 86 X 72X 14.7 mm (3.39 X 2.84 X 0.58Inch) DIP
VHA150 Series VHA150 Series Download » 150 2:1 Voltage Input 18~36VDC & 36~72VDC Single 57.9 X 61 X 13.5 mm (2.28 X 2.4 X 0.53 Inch) DIP
VDA300 Series VDA300 Series Download » 300 2:1 Input Nominal 96VDC: 65~150VDC
110VDC: 82~180VDC
280VDC: 200~400VDC		 Single 86 X 83X 14.7 mm (3.39 X 3.27 X 0.58Inch) DIP
VDA600 Series VDA600 Series Download » 600 2:1 Input Nominal 96VDC: 65~150VDC
110VDC: 82~180VDC
280VDC: 200~400VDC		 Single 146X 86X 16 mm (5.75 X 3.39 X 0.63Inch) DIP

Arch Electronics

Series... Datasheet Power Input Range Outputs Dimensions Features
SB1R5 SB1R5 Download » 2 5VDC
12VDC
24VDC
48VDC		 Single, Dual 1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm		 DC-DC PCB Mount
SB03 SB03 Download » 3 24VDCln
48VDC		 Single, Dual 1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm		 DC-DC PCB Mount
SB05 SB05 Download » 5 24VDC
48VDC		 Single, Dual 1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm		 DC-DC PCB Mount
SH05 SH05 Download » 5 24VDC
48VDC		 Single, Dual 1.25 x 0.8 x 0.44 In
31.8 x 20.3 x 11.2 mm		 DC-DC PCB Mount
ZA05 ZA05 Download » 5 24V--9-36VDC
48V--18-75VDC		 Single, Dual 1.25 x 0.8 x 0.4 In31.8 x 20.3 x 10.2 mm DC-DC PCB Mount
SB08 SB08 Download » 8 2:1 Range: 12VDC, 24VDC, 48VDC
4:1 Range: 24VDC, 48VDC		 Single, Dual 1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm		 DC-DC PCB Mount
SH08 SH08 Download » 8 24VDC
48VDC		 Single, Dual 1.25 x 0.8 x 0.44 In
31.8 x 20.3 x 11.2 mm		 DC-DC PCB Mount
SH10 SH10 Download » 10 12V--9-18VDC
24V--18-36VDC
48V--36-75VDC		 Single, Dual 1.25 x 0.8 x 0.44 In
31.8 x 20.3 x 11.2 mm		 DC-DC PCB Mount
ST10 ST10 Download » 10 2:1 Range: 12V--9-18, 24V--18-36, 28V--36-75VDC
4:1 Range: 24V--10-40, 48V--36-75VDC		 Single, Dual 1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm		 DC-DC PCB Mount
SR78/1000 SR78/1000 Download » 15 9V (4.6V-36V) 1.5V-15V 11.5 x 10.2 x 7.55 mm DC-DC PCB Mount
ST15 ST15 Download » 15 2:1 Range: 12V--9-18, 24V--18-36, 48V--36-75VDC
4:1 Range: 24F--10-40, 48V--18-75VDC		 Single, Dual 1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm		 DC-DC PCB Mount
SW15 SW15 Download » 15 128V--9-1VDC
24V--18-36VDC
48V--36-75		 Single 1.0 x 1.0 x 0.433 In
25.4 x 25.4 x 11.0 mm		 DC-DC PCB Mount
ZB15 ZB15 Download » 15 12V--9-18VDC
24V--18-36VDC
48V--36-75VDC		 Single, Dual 1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm		 DC-DC PCB Mount
SW20 SW20 Download » 20 12V--9-18VDC
24V--18-36VDC
48V--36-75VDC		 Single 1.0 x 1.0 x 0.433 In
25.4 x 25.4 x 11.0 mm		 DC-DC PCB Mount
ST20 ST20 Download » 20 2:1 Range: 24V--18-36VDC
48V--36-75VDC		 Single 1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm		 DC-DC PCB Mount
SU20 SU20 Download » 20 2:1 Range: 12VDC, 24VDC, 48VDC
4:1 Range: 24VDC, 48VDC		 Single, Dual,Triple 2.0 x 2.0 x 0.45 In
50.8 x 50.8 x 11.4 mm		 DC-DC PCB Mount
ST30 ST30 Download » 30 24VDC
48VDC		 Single, Dual 2.0 x 1.0 x 0.433 In
50.8 x 25.4 x 11.0 mm		 DC-DC PCB Mount
SF30 SF30 Download » 30 24VDC
48VDC		 Single, Dual 2.0 x 1.6 x 0.47 In
50.8 x 40.6 x 11.9 mm		 DC-DC PCB Mount
SK30 SK30 Download » 30 48V--36-75VDC Single 2.0 x 1.6 x 0.47 In
50.8 x 40.6 x 11.9 mm		 DC-DC PCB Mount
SK40 SK40 Download » 40 48V--36-75VDC Single 2.0 x 1.60 x 0.47 In
50.80 x 40.6 x 11.90 mm		 DC-DC PCB Mount
SU40 SU40 Download » 40 2:1 Range: 12V--9-18, 24V--18-36, 48V--36-75VDC Single, Dual,Triple 2.0 x 2.0 x 0.45 In
50.8 x 50.8 x 11.4 mm		 DC-DC PCB Mount

Cincon

Series... Datasheet Power Input Range Outputs Dimensions Features
EC1SAN.pdf EC1SAN.pdf Download » 1 4.5~5.5V 5V 0.77x0.24x0.40(SIP7) Isolated DC/DC Converters 1W Unregulated 4.5-5.5Vin 5Vout 0.2A
EC1TAN.pdf EC1TAN.pdf Download » 1 4.5~5.5V 5V 0.46x0.24x0.40(SIP4) Isolated DC/DC Converters 1W Unregulated 5Vin 5Vout 0.2A
EC2SAN.pdf EC2SAN.pdf Download » 2 4.5~5.5V 5V 0.77x0.28x0.40(SIP7) Isolated DC/DC Converters 2W Unregulated 4.5-5.5Vin 5Vout 0.4A
EC2SA EC2SA Download » 2 4.5~9V ±5V 0.86x0.36x0.44(SIP8) Isolated DC/DC Converters 2W 4.5-9Vin ±5Vout ±0.2A
EC5A.pdf EC5A.pdf Download » 2 4.7~6V 3.3V 1.25x0.80x0.40(DIP) Non-Isolated DC/DC Converters 6-24W 4.7-6Vin 3.3Vout 2A
EC3AB.pdf EC3AB.pdf Download » 3 9~18V 5V 1.25x0.80x0.50(DIP24) Isolated DC/DC Converters 3W 9-18Vin 5Vout 0.6A
EC3AE.pdf EC3AE.pdf Download » 3 5V 5V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 3W 4.5-9VDC 15Vout 200mA
EC3A-E EC3A-E Download » 3 4.5~9V 5V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 3W 4.5-9Vin 5Vout 0.6A
EC3A EC3A Download » 3 4.5~6V 5V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 3W 4.5-6Vin 5Vout 0.6A
EC3AW EC3AW Download » 3 9~36V 5V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 3W 9-36Vin 5Vout 0.6A
EC3SA EC3SA Download » 3 4.5~9V ±5V 0.86x0.36x0.44(SIP8) Isolated DC/DC Converters 2.31-3W 4.5-9Vin ±5Vout ±0.3A
EC3SAWH EC3SAWH Download » 3 9~36V ±5V 0.86x0.36x0.44(SIP8) 3Watts 4:1 Input Range SIP-8 Regulated DC-DC Converter Dual 9-36Vin 5Vdc Output, 3000VDC Isolation, Positive Logic
EC3SAW EC3SAW Download » 3 9~36V ±5V 0.86x0.36x0.44(SIP8) Isolated DC/DC Converters 2.31-3W 9-36Vin ±5Vout ±0.3A
EC4AW-H6 EC4AW-H6 Download » 5 9~36V ±12V 1.25x0.80x0.40 Isolated DC/DC Converters 7.5W 18-36Vin 5Vout 1500mA
EC4AB.pdf EC4AB.pdf Download » 6 9~18V 5V 1.25x0.80x0.50(DIP24) Isolated DC/DC Converters 5-6W 9-18Vin 5Vout 1A
EC4A-E EC4A-E Download » 6 9~18V 5V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 5-6W 9-18Vin 5Vout 1A
EC4A EC4A Download » 6 9~18V 5V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 5-6W 9-18Vin 5Vout 1A
EC4AW.pdf EC4AW.pdf Download » 6 9~36V 5V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 3.3-6W 9-36Vin 5Vout 1A
EC4SAW EC4SAW Download » 6 9~36V ±5V 0.86x0.36x0.44(SIP8) Isolated DC/DC Converters 5-6W 9-36Vin±5Vout ±0.6A
EC6A EC6A Download » 7 9~18V 5V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 7.5W 9-18Vin 5Vout 1.5A
EC6AW EC6AW Download » 8 9~36V ±5V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 8W 9-36Vin +/-5Vout +/-0.8A
EC2SB EC2SB Download » 10 4.7~9V ±5V 1.00x1.00x0.40(DIP) Isolated DC/DC Converters 10W 4.7-9Vin +/-5Vout +/-1A
EC2SBW-H EC2SBW-H Download » 10 9~36V ±12V 1.00x1.00x0.40(DIP) Isolated DC/DC Converters 10W 9-36Vin 12Vout 833mA with 3KV isolation dual output
EC2SBW EC2SBW Download » 10 9~36V ±5V 1.00x1.00x0.40(DIP) Isolated DC/DC Converters 10W 9-36Vin +/-5Vout +/-1A
EC4BE EC4BE Download » 10 9~18V 5V 2.00x1.00x0.40(DIP) Isolated DC/DC Converters 10W 9-18 Vin 5Vout 2A
EC4BU EC4BU Download » 10 4.7~9V ±5V 2.00x1.00x0.40(DIP) Isolated DC/DC Converters 8.25-10W 4.7-9 Vin ±5Vout ±1A
EC4BW.pdf EC4BW.pdf Download » 10 9~36V 5V 2.00x1.00x0.40(DIP) Isolated DC/DC Converters 6.6-10W 9-36 Vin 5Vout 2A
EC5DAW EC5DAW Download » 10 9~36V ±12V 0.95x0.54x0.39(DIP16) Isolated DC/DC Converters 10W, 9-36 VDC, 12Vout / ±417 mA
EC5SAW.pdf EC5SAW.pdf Download » 10 9~36V ±5V 0.87x0.37x0.47(SIP8) LOW POWER DC-DC I/P:9-36VDC O/P:±5V/±1000mA
EC6AW-110.pdf EC6AW-110.pdf Download » 10 43~160V ±5V 1.25x0.80x0.50(DIP24) Isolated DC/DC Converters 8.25-10W 43-160Vin ±5Vout ±1A
EC7A EC7A Download » 10 9~18V ±12V 1.25x0.80x0.40(DIP24) Isolated DC/DC Converters 10W 9-18Vin +/-12Vout +/-0.416A
EC7AW18 EC7AW18 Download » 10 8.5~160V ±5V 1.25x0.80x0.50(DIP24) 10 WATT 18:1 INPUT Isolated DC-DC Converter, with dual output 5V
EC7AW EC7AW Download » 10 9~36V ±12V 1.25x0.80x0.40(DIP24) 10Watts 4:1 Input Range DIP-24 Isolated DC-DC Converter 9-36Vdc Input, Dual 12Vdc Output
EC3SB EC3SB Download » 15 9~18V ±5V 1.00x1.00x0.40(DIP) Isolated DC/DC Converters 15W 9-18Vin +/-5Vout +/-1.5A
EC3SBW EC3SBW Download » 15 9~36V ±5V 1.00x1.00x0.40(DIP) Isolated DC/DC Converters 15W 9-36Vin +/-5Vout +/-1.5A
EC5BE EC5BE Download » 15 9~18V 5V 2.00x1.00x0.40(DIP) Isolated DC/DC Converters 9.9-15W 9-18 Vin 5Vout 3A
EC5BU EC5BU Download » 15 9~18V ±5V 2.00x1.00x0.40(DIP) Isolated DC/DC Converters 13.2-15W 9-18 Vin ±5Vout ±1.5A
EC5BW EC5BW Download » 15 9~36V ±5V 2.00x1.00x0.40(DIP) Isolated DC/DC Converters 13.2-15W 9-36 Vin ±5Vout ±1.5A
EC1SC EC1SC Download » 20 9~36V 5V 2.00×1.60×0.45(DIP) Isolated DC/DC Converters 20W 9-36Vin 5Vout 4A
EC4SBW EC4SBW Download » 20 9~36V ±12V 1.00x1.00x0.40(DIP) Isolated DC/DC Converters 14.85-20W 9-36 Vin ±12Vout ±0.83A
EC7B EC7B Download » 20 9~18V ±12V 2.00x1.00x0.40(DIP) Isolated DC/DC Converters 10.8-20W 9-18 Vin ±12Vout ±0.835A
EC7BW-110 EC7BW-110 Download » 20 43~160V ±12V 2.00x1.00x0.40(DIP) Isolated DC/DC Converters 19-95-20W 43-160 Vin ±12Vout ±0.833A
EC7BW18-72 EC7BW18-72 Download » 20 8.5~160V ±12V 2.00x1.00x0.40(DIP) RAILWAY LOW POWER DC-DC I/P:8.5-160VDC O/P:±12V/±833mA
EC7BW18-EC-D-RT-P EC7BW18-EC-D-RT-P Download » 20 10~160V ±12V 4.45x2.33x0.85 RAILWAY LOW POWER DC-DC I/P:9.5-160VDC O/P:±12V/±833mA
EC7BW EC7BW Download » 20 9~36V ±5V 2.00x1.00x0.40(DIP) Isolated DC/DC Converters 18.15-20W 9-36 Vin ±5Vout ±2A
EC5SBW-C-D-MF EC5SBW-C-D-MF Download » 30 10~36V ±12V 3.31x1.48x1.20 Isolated DC/DC Converters 30W 9-36Vin +/-12VDC/+/-1250mA with build in EMI filter chassis Mount Isolated DC/DC Converters
EC5SBW EC5SBW Download » 30 9~36V ±12V 1.00x1.00x0.40(DIP) Isolated DC/DC Converters 30W 9-36Vin +/-12Vout +/-1.25A
ECB40W18 ECB40W18 Download » 40 8.5~160V 5V 2.00x1.00x0.50(DIP) Isolated DC/DC Converters 40W 8.5-160 VDC 5VDC/ 8000 Ma
ECLB40W-110 ECLB40W-110 Download » 40 43~160V ±12V 2.05x1.20x0.40(DIP) 40Watts 43-160VDC 4:1 Input 2"x1.2" Railway DC-DC Converter Dual 12Vdc Output
ECLB40W ECLB40W Download » 40 9~36V 15V 2.05x1.20x0.40(DIP) Isolated DC/DC Converters 33-40W 9-36 Vin 15Vout 2.666A
CHB50 CHB50 Download » 50 9~18V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 33-50W 9-18 Vin 5Vout 10A
CHB50W CHB50W Download » 50 9~36V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 33-50W 9-36 Vin 5Vout 10A
CQB50W12-CMFC-D CQB50W12-CMFC-D Download » 50 14~160V 5V 4.60x2.40x1.26 RAILWAY BRICK DC-DC CQB50W12-72S05N-CMFC
CQB50W12 CQB50W12 Download » 50 14~160V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 30-50W 14-160 Vin 5Vout 6A
CQB50W8-CMFC-D CQB50W8-CMFC-D Download » 50 9.5~75V 12V 4.60x2.40x1.46 RAILWAY BRICK DC-DC CQB50W8-36S12-CMFC
CQB50W8 CQB50W8 Download » 50 9~75V 12V 2.28×1.45x0.50 RAILWAY BRICK DC-DC I/P:9-75VDC O/P:12V/4.17A
CQE50W CQE50W Download » 50 9~36V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 33-50W 9-36 Vin 10A
CQB60W-110S CQB60W-110S Download » 60 43~160V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 60W 43-160 Vin 5Vout 12A
ECLB60W ECLB60W Download » 60 9~36V ±12V 2.05x1.20x0.40(DIP) I/P:9-36VDC O/P:±12V/±2.5A
CHB75.pdf CHB75.pdf Download » 75 9~18V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 49.5-75W 9-18 Vin 5Vout 15A
CHB75W CHB75W Download » 75 9~36V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 49.5-75W 9-36 Vin 5Vout 15A
CQB75-300S-CMFC-D CQB75-300S-CMFC-D Download » 75 180~450V 5V 4.60x2.40x1.24 HIGH INPUT BRICK DC-DC CQB75-300S05-CMFC
CQB75W14 CQB75W14 Download » 75 12~160V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 75W, 12-160V VOUT 5V/15000mA
CQB75W8-36S-CMFC-D CQB75W8-36S-CMFC-D Download » 75 9.5~75V 12V 4.60x2.40x1.46 RAILWAY BRICK DC-DC CQB75W8-36S12-CMFC
CQB75W8 CQB75W8 Download » 75 9~75V 12V 2.28×1.45x0.50 RAILWAY BRICK DC-DC I/P:9-75VDC O/P:12V/6.25A
CQB75W CQB75W Download » 75 9~36V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 39.6-75W 9-36 Vin 5Vout 12A
ECLB75W ECLB75W Download » 75 9~36V ±12V 2.05x1.20x0.40(DIP) I/P:9-36VDC O/P:±12V/±3.12A
CQB75-300S CQB75-300S Download » 95 180~450V 5V 2.28×1.45x0.50 HIGH INPUT BRICK DC-DC I/P:180-450VDC O/P:5V/15A
CHB100-110S.pdf CHB100-110S.pdf Download » 100 66~160V 12V 2.28×2.40x0.50 Isolated DC/DC Converters 99.6-100W 66-160 Vin 12Vout 8.3A
CHB100 CHB100 Download » 100 18~36V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 66-100W 18-36 Vin 5Vout 20A
CHB100W.pdf CHB100W.pdf Download » 100 9~36V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 66-100W 9-36 Vin 5Vout 20A
CHB50-100W-CM-DIN CHB50-100W-CM-DIN Download » 100 9~36V 5V 4.61x2.54x1.03 Half Brick Chassis Mount / DIN Rail DC-DC Converter Module
CQB100-110S CQB100-110S Download » 100 66~160V 5V 2.28×1.45x0.50 RAILWAY BRICK DC-DC I/P:66-160VDC O/P:5V/20A
CQB100W.pdf CQB100W.pdf Download » 100 9~36V 5V 1.45 x 2.28 x 0.50 Isolated DC/DC Converters 99-100W 9-36 Vin 5Vout 20A
CQB100W-110S-CMFC-D CQB100W-110S-CMFC-D Download » 100 43~160V 5V 4.60x2.40x1.26 RAILWAY BRICK DC-DC CQB100W-110S05-CMFC
CQB100W-110S CQB100W-110S Download » 100 43~160V 5V 2.28×1.45x0.50 RAILWAY BRICK DC-DC I/P:43-160VDC O/P:5V/20A
CQB100W14 CQB100W14 Download » 100 12~160V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 100W, 12-160V VOUT 5V/20000mA
CQB50-150W-CMDIN.pdf CQB50-150W-CMDIN.pdf Download » 100 9~36V 12V 4.41x1.57x1.98 BRICK DC-DC I/P:9-36VDC O/P:12V/8.3A
CEB100W CEB100W Download » 100 9~40V 5V 2.45×1.05x0.50 100Watts 4:1 Input Range Eighth Brick DC-DC Converter
CQB100W8 CQB100W8 Download » 100 9~75V 5V 2.28×1.45x0.50 9-75VDC 8:1 Input Quarter Brick Railway DC-DC Converter
CHB150-110S.pdf CHB150-110S.pdf Download » 150 66~160V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 150-156W 66-16 Vin 5Vout 30A
CHB150 CHB150 Download » 150 36~75V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 99-150W 36-75 Vin 5Vout 30A
CHB150W12-72S CHB150W12-72S Download » 150 14~160V 5V 2.28×2.40x0.50 RAILWAY BRICK DC-DC I/P:14-160VDC O/P:5V/25A
CHB150W8 CHB150W8 Download » 150 9~75V 12V 2.28×2.40x0.50 Isolated DC/DC Converters 150W 9-75 Vin 12Vout 12.5A
CHB150W CHB150W Download » 150 9~36V 5V 2.28×2.40x0.52 Isolated DC/DC Converters 99-150W 9-36 Vin 5Vout 30A
CQB150-300S-CMFC-D CQB150-300S-CMFC-D Download » 150 180~425V 5V 4.60x2.40x1.26 HIGH INPUT BRICK DC-DC CQB150-300S05-CMFC
CQB150-300S CQB150-300S Download » 150 180~425V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 150W 180-425 Vin 5Vout 30A
CQB150W-110S CQB150W-110S Download » 150 43~160V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 150W 43-160 Vin 5Vout 30A
CQB150W14 CQB150W14 Download » 150 12~160V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 150W, 12-160V VOUT 5V/25000mA
CQB150W CQB150W Download » 150 9~36V 5V 2.28×1.45x0.50 Isolated DC/DC Converters 150W 9-36 Vin 5Vout 30A
https://www.cincon.com/productdownload/SPEC-CQB150W-110S-CMFC-D https://www.cincon.com/productdownload/SPEC-CQB150W-110S-CMFC-D Download » 150 43~160V 5V 4.60x2.40x1.26 Isolated DC/DC Converters DC-DC Converter, Quarter Brick, Chassis Mount, 150 Watt, 4:1 Input Range, 43-160VAC Input, 5VDC Output, 89% Efficiency, 30000 F
CQB150W8 CQB150W8 Download » 150 9~75V 5V 2.28×1.45x0.50 9-75VDC 8:1 Input Quarter Brick Railway DC-DC Converter
CHB200W CHB200W Download » 200 10~36V 5V 2.28×2.40x0.52 Isolated DC/DC Converters 165-200W 10-36 Vin 5Vout 40A
CHB200W-110S.pdf CHB200W-110S.pdf Download » 200 43~160V 5V 2.28×2.40x0.50 RAILWAY BRICK DC-DC I/P:43-160VDC O/P:5V/40A
CHB200W-110S-CMFC-D CHB200W-110S-CMFC-D Download » 200 43~160V 5V 6.50x3.00x1.52 RAILWAY BRICK DC-DC CHB200W-110S05-CMFC
CHB200W12-72S-CMFD CHB200W12-72S-CMFD Download » 200 14~160V 12V 6.98x3.09x1.56 Chassis Mount, 200W, 12:1 14-160Vdc Input, Single 12Vdc Output, Positive Logic, With Cover
CHB200W12-72S CHB200W12-72S Download » 200 14~160V 12V 2.28×2.40x0.50 RAILWAY BRICK DC-DC I/P:14-160VDC O/P:12V/16.7A
CQB200 CQB200 Download » 200 18~36V 24V 2.28×1.45x0.50 CQB200 SERIES 200 WATT 2:1 INPUT ISOLATED DC-DC CONVERTER
CHB300-300S CHB300-300S Download » 300 180~425V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 300W 180-425 Vin 5Vout 60A
CHB300-300SXX-CMFC-D CHB300-300SXX-CMFC-D Download » 300 180~425V 5V 6.50x3.00x1.52 Isolated DC/DC Converters 231-350W 18-36 Vin 5 Vout 60A Chassis mount
CHB300W CHB300W Download » 300 9~36V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 300W 9-36 Vin 5Vout 60A
CHB300W-110S.pdf CHB300W-110S.pdf Download » 300 43~160V 5V 2.28×2.40x0.50 Isolated DC/DC Converters 300W 43-160 Vin 5Vout 60A
CHB300W-110S-CMFC-D CHB300W-110S-CMFC-D Download » 300 43~160V 5V 6.50x3.00x1.52 RAILWAY BRICK DC-DC CHB300W-110S05-CMFC
CHB350 CHB350 Download » 350 18~36V 5V 2.28x2.40x0.52 (Standard) Isolated DC/DC Converters 231-350W 18-36 Vin 5Vout 70A
CFB400W.pdf CFB400W.pdf Download » 400 9~36V 5V 4.60×2.40x0.50 Isolated DC/DC Converters 400W 9-36 Vin 5Vout 80A
CHB500W CHB500W Download » 500 9~40V 12V 2.28×2.40x0.50 500Watts 4:1 Input Range Half Brick DC-DC Converter
CFB600-300S CFB600-300S Download » 600 180~425V 12V 4.60×2.40x0.50 Isolated DC/DC Converters 600W 180-425 Vin 12Vout 50A
CFB600 CFB600 Download » 600 18~36V 12V 4.60×2.40x0.50 Isolated DC/DC Converters 600-700W 18-36 Vin 12Vout 50A
CFB600W-110S-CMFD CFB600W-110S-CMFD Download » 600 43~160VDC 12V 9.45x4.33x1.65 Isolated DC/DC Converters 300W 180-425 Vin 48Vout 6.25A
CFB600W-110S CFB600W-110S Download » 600 43~160VDC 12V 4.60×2.40x0.50 Isolated DC/DC Converters 300W 180-425 Vin 48Vout 6.25A
PDF700S-B-CMFC-D-D-P PDF700S-B-CMFC-D-D-P Download » 700 90-264 12V CMFC:9.45x4.33x1.587 CMFD(D-P):9.45x4.33x1.654 Switching Power Supplies AC-DC Switching Power Module, 90-264VAC Input, 700W, 12VDC Output Built-In EMI Filter
CFB750-300S-CMFD CFB750-300S-CMFD Download » 750 200~425V 12V 9.45x4.33x1.65 Isolated DC/DC Converters 750W 200-425 Vin 12Vout 62.5A, with CMFD
CFB750-300S CFB750-300S Download » 750 200~425V 12V 4.60×2.40x0.50 Isolated DC/DC Converters 750W 200-425 Vin 12Vout 62.5A
CFB800 CFB800 Download » 800 18~36V 28V 4.60×2.40x0.50 Isolated DC/DC Converters 800W Vin 18-36VDC, 24Vout . 28.5A

Integrated Power Designs

Series... Datasheet Power Input Range Outputs Dimensions Features
VXB20(W) Series VXB20(W) Series Download » 20 2:1 Input Nominal 12VDC: 9~18
24VDC: 18~36
28VDC: 18~36
4:1 Input Nominal 24VDC: 15~55
28VDC: 15~55		 Single 50.8 X 25.4 X 12.7 mm (2 X 1 X 0.5 Inch) DIP
VDB30 Series VDB30 Series Download » 30 2:1 INPUT 12VDC: 9~18VDC
24VDC: 18~36VDC
48VDC: 36~72VDC		 Single 50.8 X 25.4 X 11.20 mm (2.00 X 1.6 X 0.4 4Inch) Enclosed
